Octagon - Fancy Expert

Process

  • ROUND
  • PEAR
  • MARQUISE
  • OVAL
  • PRINCESS
  • EMERALD
  • BAGUETTE
  • LOZENGE
  • TAPERED BAGUETTE
  • HEART


  • 1
    Only machine which delivers excellent and accurate Fancy cutting
  • 2
    Capable to cut Fancy shapes with accurate dimensions.
  • 3
    Accurate shape gives minimum polishing time and maximum Profit.
  • 4
    Minimum setting time and easy operation enables fast production.
  • 5
    Dedicated parameters files for different shapes and sizes for easy operation.
  • 6
    Different faceting patterns for round shape.
  • 7
    QR code reader for direct entry of parameters.
  • 8
    Rugged and Heavy structure for minimum Vibrations.
  • 9
    Highest Up-time and Low maintenance cost.
  • Laser
    : Nd:YAG DPSSL
  • Spatial Mode
    : TEM 00
  • Wavelength
    : 1064 nm
  • Polarization
    : Linear
  • Beam Roundness
    : >90%
  • Average Power
    : >16 W
  • Repetition Rate
    : 6-12 KHz
  • Cooling Water
    : Steam Distilled
  • Axis Travel
    : 130mm x 130mm x 70mm
  • Resolution
    : 2 Micron
  • Accuracy
    : 2 Micron / 25mm
  • Repeatability
    : 2 Micron / 25Micron Bidirection
  • Driver
    : AC Servo & Stepper
  • Power Requirement
    : 220 VAC +10%,1 Phase,50Hz
  • Power Consumption
    : <2.5 KVA
  • Room Temperature
    : 240 C - 260C
  • Length x Width x Height
    : 1500mm x 650mm x1500mm
  • Weight
    : 370Kg
